POWER
Power supply AC 110-240V ±10%, 50/60Hz
Power supply DC 24 V ±10%,
Channels 2 channels
Max. current per channel 10A
Max. total device current 16A (18A peak)
Max. switching voltage 240 VAC / 30 VDC
SPECIAL FUNCTIONS
Dry contacts No
Cover (roller) control Yes, with position control - roller shutters, blinds, awnings, curtains, gates, shades, sliding door, garage door, bi-directional AC motors
Overload protection Yes
Power measurement Yes
Working without a neutral line No
FEATURES
HTTP/HTTPS webhooks Yes
Custom scripts (mJs) Yes
Operational temperature 0 to + 40 °C
Device power consumption < 1.4 W
Local and remote control Yes
Sunrise/Sunset Yes
Weekly Schedule Yes
UL Listed option No
CONNECTIVITY
Wireless 802.11 b/g/n
Wi-Fi Radio frequency 2400 – 2500 MHz
Wi-Fi Radio signal power 1mW
Wi-Fi Range up to 50 m outdoors and up to 30 m indoors (depending on the building materials)
DIMENSIONS
Size 42x38x17 mm
